10 Best Practices for Apache Hive

By Nate PhilipJune 26, 2014


Apache Hive is an SQL-like software used with Hadoop to give users the capability of performing SQL-like queries on it’s own language, HiveQL, quickly and efficiently . It also gives users additional query and analytical abilities not available on traditional SQL structures.

With Apache Hive, users can use HiveQL or traditional Mapreduce systems, depending on individual needs and preferences. Hive is particularly ideal for analyzing large datasets (petabytes) and also includes a variety of storage options.

Hive is full of unique tools that allow users to quickly and efficiently perform data queries and analysis. In order to make full use of all these tools, it’s important for users to use best practices for Hive implementation. Here are 10 ways to make the most of Hive.

1. Partitioning Tables:

Hive partitioning is an effective method to improve the query performance on larger tables (Tweet this). Partitioning allows you to store data in separate sub-directories under table location. It greatly helps the queries which are queried upon the partition key(s). Although the selection of partition key is always a sensitive decision, it should always be a low cardinal attribute, e.g. if your data is associated with time dimension, then date could be a good partition key. Similarly, if data has association with location, like a country or state, then it’s a good idea to have hierarchical partitions like country/state.

2. De-normalizing data:

Normalization is a standard process used to model your data tables with certain rules to deal with redundancy of data and anomalies. In simpler words, if you normalize your data sets, you end up creating multiple relational tables which can be joined at the run time to produce the results. Joins are expensive and difficult operations to perform and are one of the common reasons for performance issues (Tweet this). Because of that, it’s a good idea to avoid highly normalized table structures because they require join queries to derive the desired metrics.

3. Compress map/reduce output:

Compression techniques significantly reduce the intermediate data volume, which internally reduces the amount of data transfers between mappers and reducers. All this generally occurs over the network. Compression can be applied on the mapper and reducer output individually. Keep in mind that gzip compressed files are not splittable. That means this should be applied with caution. A compressed file size should not be larger than a few hundred megabytes (Tweet this). Otherwise it can potentially lead to an imbalanced job. Other options of compression codec could be snappy, lzo, bzip, etc.

  • For map output compression set to true
  • For job output compression set mapred.output.compress to true

For more functions, check out the Hive Cheat Sheet.

4. Map join:

Map joins are really efficient if a table on the other side of a join is small enough to fit in the memory (Tweet this). Hive supports a parameter,, which when it’s set to “true” suggests that Hive try to map join automatically. When using this parameter, be sure the auto convert is enabled in the Hive environment.

5. Bucketing:

Bucketing improves the join performance if the bucket key and join keys are common. (Tweet this) Bucketing in Hive distributes the data in different buckets based on the hash results on the bucket key. It also reduces the I/O scans during the join process if the process is happening on the same keys (columns).

Additionally it’s important to ensure the bucketing flag is set (SET hive.enforce.bucketing=true;) every time before writing data to the bucketed table. To leverage the bucketing in the join operation we should SET hive.optimize.bucketmapjoin=true. This setting hints to Hive to do bucket level join during the map stage join. It also reduces the scan cycles to find a particular key because bucketing ensures that the key is present in a certain bucket.

6. Input Format Selection:

Input formats play a critical role in Hive performance. For example JSON, the text type of input formats, is not a good choice for a large production system where data volume is really high. (Tweet This) These type of readable formats actually take a lot of space and have some overhead of parsing ( e.g JSON parsing ). To address these problems, Hive comes with columnar input formats like RCFile, ORC etc. Columnar formats allow you to reduce the read operations in analytics queries by allowing each column to be accessed individually. There are some other binary formats like Avro, sequence files, Thrift and ProtoBuf, which can be helpful in various use cases too.

7. Parallel execution:

Hadoop can execute MapReduce jobs in parallel, and several queries executed on Hive automatically use this parallelism. However, single, complex Hive queries commonly are translated to a number of MapReduce jobs that are executed by default sequencing. Often though, some of a query’s MapReduce stages are not interdependent and could be executed in parallel. They then can take advantage of spare capacity on a cluster and improve cluster utilization while at the same time reducing the overall query executions time. The configuration in Hive to change this behavior is merely switching a single flag SET hive.exec.parallel=true.

8. Vectorization:

Vectorization allows Hive to process a batch of rows together instead of processing one row at a time. (Tweet This) Each batch consists of a column vector which is usually an array of primitive types. Operations are performed on the entire column vector, which improves the instruction pipelines and cache usage. To enable vectorization, set this configuration parameter SET hive.vectorized.execution.enabled=true.

9. Unit Testing:

Simply speaking, unit testing determines whether the smallest testable piece of your code works exactly as you expect. Unit testing gives a couple of benefits i.e. detecting problems early, making it easier to change and refactor code, being a form of documentation that explains how code works, to name a few.

In Hive, you can unit test UDFs, SerDes, streaming scripts, Hive queries and more. To a large extent, it is possible to verify the correctness of your whole HiveQL query by running quick local unit tests without even touching a Hadoop cluster. Because executing HiveQL query in the local mode takes literally seconds, compared to minutes, hours or days if it runs in the Hadoop mode, it certainly saves huge amounts of development time.

There are several tools available that helps you to test Hive queries. Some of them that you might want to look at HiveRunner, Hive_test and Beetest.

10. Sampling:

Sampling allows users to take a subset of dataset and analyze it, without having to analyze the entire data set. If a representative sample is used, then a query can return meaningful results as well as finish quicker and consume fewer compute resources.

Hive offers a built-in TABLESAMPLE clause that allows you to sample your tables. TABLESAMPLE can sample at various granularity levels – it can return only subsets of buckets (bucket sampling), or HDFS blocks (block sampling), or only first N records from each input split. Alternatively, you can implement your own UDF that filters out records according to your sampling algorithm.

For more tips on how to perform efficient Hive queries, see this blog post.
